Progress Lighting - P806N-N-MD-ICAT - 90W Air-Tight IC New Construction Housing In Utilitarian Style-7.38 Inches Tall and 9.4 Inches Wide

Item # P806N-N-MD-ICAT Product Details
$15.20
3 Day Delivery or Get $25 Back View Details
  Free Shipping on orders over $49!
    Update  Cancel
Decrease Qty
Increase Qty

This 6 in. Recessed Housing with Quick Link Connector has several great installation features plus an Air-Tight rating. It is ideal for IC and non-IC new construction applications. Its gasketed Air-Tight housing restricts airflow from conditioned spaces into unconditioned attic space, preventing unnecessary HVAC costs and improving the overall home energy efficiency. The housing and frame are constructed from die-formed corrosion resistant galvanized steel. The lamp housing compartment can be adjusted to fit ceiling thicknesses from ½ in. To 1 ¼ in. It features a universal J-box with snap-out sides. Wiring is made easy with the included wiring quick-connects that allow simple installation of 12-20 AWG wire without using separate wire nuts - simply strip supply wires and push in. The housing has pre-installed nails on the adjustable hanger bars which are easily installed in regular lumber, engineered lumber, and laminated beams. Hanger bars include t-bar mounting clamps for use in suspended t-grid ceilings. The bar hangers have a maximum span of 24 in. And are scored in two locations for fast, clean breaking, allowing housing installation in very narrow joist spacings. It is UL and CUL listed for damp locations and is thermally protected against improper use of lamps.
The housing and frame are constructed from die-formed corrosion resistant galvanized steel
Its gasketed air-tight lamp housing prevents conditioned air from escaping into the attic space, reducing unnecessary HVAC energy usage, and the lamp housing compartment can be adjusted to fit ceiling thicknesses from ½ in. To 1 ¼ in.
Wiring is made easy with the included wiring quick-connects that allow simple installation of 12-20 AWG wire without using separate wire nuts - simply strip supply wires and push in
Bar hangers have a maximum span of 24 in. And are scored in two locations for fast, clean breaking, allowing housing installation in very narrow joist spacings, and Includes pre-installed framing nails on the bar hangers, making installation quick and efficient and the hanger bars include t-bar mounting clamps for use in suspended t-grid ceilings
Features a universal J-box with snap-out sides
Measures 6.61 in. L x 9.4 in. W x 7.375 in. H
Uses 1 BR40 light source (sold separately) 90-watt maximum
The housing is compatible with a variety of trims and finishes
cULus damp location rating makes this trim ideal for use in a variety of room settings where water may be present
Warranty: Our 1-Year Limited Warranty guarantees your complete satisfaction with your purchase and includes professional after-sales customer service support

Dimensions & Weights
Length:
6.61"
Width/Diameter (in):
9.4"
Height:
7.38"
Weight:
2.41 lbs
Lamping Details
# of Bulbs:
1
Standard Wattage:
90 Watts
Bulb Type:
Incandescent
Lamp Base Type:
BR40
Product Details
Finish:
Unfinished
Design Style:
Modern, Traditional, Transitional, Utilitarian
Voltage Rating:
120 V
Material:
Steel
Warranty:
1 Year Limited
Made In:
China
What is Included
Bulbs Included:
No
This product is Energy Efficient.
This product is Damp Rated and suitable for humid environments like bathrooms or covered outdoor locations
This product is UL Certified.
This product is cUL Certified.
